Zurn Z806

Zurn Z806

Channel Length: 60″
Width: 6″
Material: Stainless Steel 304

Category: Manufacturer: Grate Materials: ,

Description

Zurn Z806



Channel Length 10′
Channel Width (OD) 6″
Channel Width (ID) 4″
Outlet Sizes 3″ S&D, 4″ S&D
Grate Width 6″
Material Polyester





Features:

  • Zurn Z806 6″ wide pre-sloped poly trench drain
  • Durable channel and heavy duty grates
  • All sections are 48-inch modular lengths with integral top frame
  • Glass-filled polyester fiberglass drain channel with .75% bottom slope.
  • All sections are modular 10-foot lengths with interlocking ends.
  • Complete with heavy-duty, Dura-Coated steel frame with anchor studs at surface, combination anchor tabs/leveling devices at appropriate locations and heavy-duty cast iron grate with lockdown.





Specifications:

Channels shall be 120 [3048] long, 6 [152] wide and have a 4 [102] throat. Modular channel sections shall be made of Fiber Reinforced Polymer (FRP). Shall have a positive mechanical connection between channel sections that will not separate during the installation and shall mechanically lock into the concrete surround every 10 [254].

Channels shall weigh less than 2.31 lbs.[1.05kg] per linear foot, have a smooth, 1-1/2 [38] radiused self cleaning bottom with a Manning’s coefficient of .009 and .75% or neutral 0% built in slope. Shall be provided with standard DGC grates that lock down to frame.

Zurn 6 [152] wide reveal Ductile Iron Slotted Grate conforming to ASTM specification A536-84, Grade 80-55-06. Ductile Iron grate is rated class C per the DIN EN1433 top load classifications. Supplied in 20 [508] nominal lengths with 1/2 [13] wide slots, and 3/4 [19] bearing depth. Grate has an open area of 18.57 sq. in per ft. [39,307 sq. mm per meter].

The 1/4 [6] thick Heavy-Duty Carbon Steel Frame Assembly conforms to ASTM specification A36 with 12-4 [102] long concrete anchors per 120 [3048]. Grate lockdown bars are to be integral to the frame. The frame is supplied with a powder coated finish. All welds must be performed by a certified welder per ASTM standard AWS D1.1. Frames Shall be produced in the U.S.A.



Z806 Specifications
